Nano 304-Grade Smart Kitchen Sink with Waterfall

A Smart Kitchen Sink Run From One Knob

The Nano puts a pull-out faucet, a Wide Waterfall, a glass rinser and an RO tap on one deck. One-Knob Control runs the waterfall and the pull-out: turn right for the waterfall, left for the pull-out; the farther you turn, the hotter the water. One outlet runs at a time. Hot water up to 60°C from any geyser. See all our kitchen sinks.

Wide Waterfall, Hot or Cold

A wide shower-style waterfall for rinsing vegetables, plates and pans. It takes hot or cold water from the same knob.

3-Mode Spray Head Pull-Out Faucet

The pull-out faucet has a 304-Grade stainless steel body, a 35 mm ceramic cartridge and a 1.5 m hose with a counterweight that draws the head back. The round push button gives Sector flow and the two-way switch gives Spray (top) or Stream (bottom). It stands 380 mm above the countertop with a 335 mm reach.

Built-in Glass Rinser and Dedicated RO Tap

Turn a glass upside down, press it down on the rinser, and it gets rinsed. The rinser uses cold water and takes glasses 50–100 mm across. The Dedicated RO Tap is its own 304-Grade tap fed straight from your RO purifier, with a quarter-turn lever; it is tested to withstand 500,000 operations. The RO connector is in the box.

Top-Fill Soap Dispenser

The soap dispenser holds 300 ml and refills from the top.

A Handmade 304-Grade Stainless Steel Bowl

The bowl is handmade from 304-Grade stainless steel, with Handcrafted easy-clean corners. Self-healing chromium shield: the 18% chromium in 304-Grade steel forms an invisible layer that protects against rust and re-forms if scratched. Silent Base: rubber pads under the bowl help reduce noise from pots and running water. The bowl is PVD Matt Black, colour bonded to the steel in a vacuum chamber, not painted on, and a Nano coating resists moisture and rust. The panel, knob, pull-out faucet, RO tap, soap dispenser and baskets are Matt Black too.

In the Box

A wooden chopping board (355 x 260 x 17 mm), a strainer basket and a vegetable basket come in the box.

Drop-in Fit for a 28.1 x 16.5 Inches Cutout

The Nano is a drop-in (top-mount) sink: it rests on its rim in a 715 x 420 mm (28.1 x 16.5 Inches) countertop cutout, with no clips, screws or silicone. Keep at least 65 mm between the back of the cutout and the wall, and 430 mm of space under the sink. Undermount installation is not recommended. The sink needs about 40 PSI (2.8 bar) at its water inlet. With a high overhead tank (about four floors up) and ¾ Inch pipes with few bends, no pump is needed. Otherwise fit a 1.5 HP pump with a 24-litre tank. We recommend a plumber, or book Home Installation, available in serviceable cities: sink bowl ₹1,599 and control panel ₹1,999 (T&C).

Backed by Ruhe

India's Biggest Digital First Brand · Kitchen & Bathroom Fittings. Designed and manufactured by Ruhe. Every piece passes our 3-step quality check before it leaves the factory. Up to 25-year warranty. Free onsite service for 1 year in serviceable cities. 30-Day Easy Returns on unused products. Report damage, a fault or a wrong product within 48 hours of delivery, before fitting.

Features

Why choose

Nano, Piano or Opera?

Have a question? Talk to a Ruhe expert on video call (Mon–Sat, 10 AM–6:30 PM, closed on public holidays), or visit a Ruhe store near you.

Also called: smart sink, waterfall kitchen sink, kitchen sink with waterfall tap, multifunctional kitchen sink, kitchen sink with pull out faucet

• 1 × Sink bowl – Handmade 304-Grade stainless steel, PVD Matt Black, 757 x 457 x 220 mm (±5 mm)
• 1 × Control panel – Pull-out faucet with 3-Mode Spray Head (Spray, Stream and Sector flow, 1.5 m hose), Wide Waterfall and One-Knob Control
• 1 × Glass rinser – Built-in Glass Rinser: press a glass down to rinse it
• 1 × RO tap – Dedicated RO Tap with a quarter-turn lever
• 1 × Soap dispenser – Top-Fill Soap Dispenser, 300 ml
• 1 × Chopping board – Wooden, 355 x 260 x 17 mm
• 1 × Strainer basket – Matt Black
• 1 × Vegetable basket – Matt Black
• 1 × Sink coupling – 4.5 Inch (114 mm)
• 1 × Waste pipe – 670 mm
• 1 × Overflow pipe – 635 mm
• 2 × Connection pipes – 24 Inch (610 mm) each, ½ Inch BSP, for the hot and cold water points
• 1 × RO connector – Connects the RO tap to your RO purifier's outlet pipe (¼ Inch)

Every sink comes with a protective plastic film, clear or coloured. Keep it on during installation and construction work, then peel it off.

• Drop-in (top-mount) only: the sink rests on its rim in a 715 x 420 mm (28.1 x 16.5 Inches) countertop cutout, with no clips, screws or silicone; undermount installation is not recommended
• Keep at least 65 mm between the back of the cutout and the wall, and 430 mm of space under the sink; no cutout template comes in the box
• Every deck hole must be fitted with its tap or fitting
• Two 24 Inch (610 mm) connection pipes, ½ Inch BSP, for the hot and cold angle valves; sink coupling 4.5 Inch (114 mm); 670 mm waste pipe and 635 mm overflow pipe in the box
• RO tap: connect your RO purifier's outlet pipe with the ¼ Inch RO connector in the box
• You arrange: angle valves on the hot and cold water points, and an RO purifier under the counter for the RO tap
• Hot water up to 60°C from any geyser; every outlet also works on cold water alone; the glass rinser uses cold water only
• The sink needs about 40 PSI (2.8 bar) at its water inlet. With a high overhead tank (about four floors up) and ¾ Inch pipes with few bends, no pump is needed. Otherwise fit a 1.5 HP pump with a 24-litre tank.
• No power point is needed
• We recommend a plumber. Home Installation, available in serviceable cities: sink bowl ₹1,599 and control panel ₹1,999 (T&C)

Delivery

• Delivered to your door across India. Enter your pincode on this page to see the estimated delivery time. The carton is heavy, so you may need to lend a hand getting it inside.
• Check the carton on arrival and report any damage within 48 hours, before fitting – details.
• Fully unpack only when you are ready to install; keep the carton until installation is done.
• Every sink comes with a protective plastic film, clear or coloured. Keep it on during installation and construction work, then peel it off.
